Support
Welcome to the Artome Support Center! Find resources to use and troubleshoot your products, from video conferencing to solving power or audio issues. For further assistance, our contact details are below. Explore to enhance your Artome experience.
Quick Help
- Check that the power cable is plugged into a power socket.
- Also make sure the other end is plugged into Artome.
- Press the power button on Artome button panel.
- Plug the HDMI cable into your computer.
- Also make sure the far end of the HDMI cable is plugged into Artome .
- Press the source button on Artome button panel.
- Check your computer display settings.
- Adjust the volume by pressing the volume + button on Artome button panel.
- Select Epson PJ as sound output on your computer.
- Check that audio is not muted on your computer.
- Check that audio is not muted in the application you’re using.
- Make sure the microphone cord / wireless receiver is connected to Artome MIC port.
- Make sure the wireless transmitter and wireless receiver are turned on.
- Make sure the manual gain knob is not set to ∞ infinity.
- Make sure the microphone is not muted.
- Camera connections are only available for Artome M10 and Artome X20
- Check that the USB cable is connected to your computer.
- Also make sure the far end of the cable is connected to Artome.
- Check if there’s any status LED in the camera indicating power.
- Make sure the USB cable is connected between the camera and Artome.
- Make sure you have selected the right camera in your video conferencing app.
- Camera connections are only available for Artome M10 and Artome X20
- Navigate to video conferencing app settings on your computer.
- If you’re using a handheld or a wireless microphone:
- Select Artome Hybridock as input device.
- In case you’re using a videobar, speakerphone or camera microphone:
- Look for input devices named after the device manufacturer.
Guides & Manuals
How to connect your laptop for presentations or videoconferencing ->
Contact
Support USA
support@artomeusa.com
Rest of the world:
support@artome.fi
Artome Products
Artome is a movable and installation-free presentation solution that offers high-quality sound system and hybrid features, enabling effortless and versatile use in various environments.
Artome S1
Every teacher’s ideal companion in transforming classes to active learning experiences.
Artome S1 is every teacher’s ideal sidekick in transforming classes to active learning experiences. Its image and sound are easily manageable with your own device. Bring the big picture and big sound exactly where you need it. Eliminate the situation with any loose wires in the classroom -Artome S1 enables effortless user experience and minimizes the need for any extra cables.
All you need is one HDMI-cable connected to your own device and you're ready to produce sound and image easily.
- Image size: 90-120"
- 2.1. -sound system
- Wireless microphone (option)
| Artome S1 | |
|---|---|
| Dimensions | (W x H x D) 52 x 81 x 48,5 cm |
| Operating temperature | 30 °C / 32-86 °F |
| 19″ rack | 3U x 280 mm / 11” (depth) |
| Supply Voltage | 100-240V ~50-60Hz |
| Warranty | 24 Months, Projector 60 Months |
| Compatible projectors | Epson EB-770F/775F/769W |
| Resolution | EB-770/775 Full HD, EB-760W HD Ready, 16:9 |
| Brightness | 4100lm |
| Sound | Embedded 2.1. -sound system |
| Recommended image size | 90″-120″ |
| Connections | HDMI 1, HDMI 2, 2kpl Mic in, power socket (100-240V) |
| Controls | Power, Source, Vol +/-, Pause, Freeze, Mic gain |
Artome M10
All-in-one solution that combines nordic design with integrated laser projector, embedded soundsystem and videoconferencing features.
Artome M10 is a movable smart furniture that displays up to a 150” image with an Epson laser projector, produces pure sound through an embedded sound system and enable local presentation and easy videoconferencing with an integrated camera and microphones.
- image size: 60-150″
- 2.1. -sound system
- Artome Hybridock™
- USB -camera (option)
- Wireless microphone (option)
| Artome M10 | |
|---|---|
| Dimensions | (W x H x D) 52 x 80 x 47,5 cm |
| Weight | 49 kg |
| 19″ rack | 3U |
| Package size | (W x H x D) 80 x 94 x 60 cm |
| Warranty | 24 Months, Projector 5 years or 12000h |
| Projector | Epson EB-805F |
| Resolution | Full HD 1080p, 16:9 |
| Brightness | 5000lm |
| Sound | Embedded 2.1. -sound system Max. SPL 108 dB @ 1 m |
| Image size | 60″-150″ |
| Connections | 2 X HDMI in, HDMI out, 2 X Mic in, Stereo audio out (balanced), HDBaseT |
| Controls | Power, Source, Vol +/-, Pause, Freeze |
Artome X20
Movable and installation-free all-in-one solution that brings large-scale display and easy-to-use sound system to large spaces.
Artome X20 transforms large spaces for events and experiences with highly versatile Epson laser projector and embedded sound system. It is movable and installation free solution that you can easily operate with your laptop through HDMI. Artome X20 brings ease of use to audiovisual technology with plug and play features.
The light output of 7000-10000 lumens produced by the Epson laser projector meets the needs of the most challenging and bright spaces. With optional interchangeable lenses Artome X20 is compatible with any kind of projection environments.
- Image size: up to 300"
- 2.1. -sound system
- Artome Hybridock™
- USB -camera (option)
- Wireless microphone (option)
Projector and Lens options
- EB-PU1007W, EB-PU1008W, EB-PU2010W
- ELPLU04 (default), ELPW06,ELPLM15, ELPLL08. For other options, please contact Artome representatives.
| Artome X20 | |||
|---|---|---|---|
| Dimensions | (W x H x D) 62 x 95 x 63cm | ||
| Weight | 80 kg | ||
| 19″ rack | 2U 34,5cm (D) | ||
| Wheels | 100mm, lockable | ||
| Warranty | 24 Months, Projector 3 years | ||
| Projector | Epson projector options: EB-PU1007 / EB-PU1008 / EB-PU2010 | ||
| Lens | ELPLU04 (default), ELPW06,ELPLM15, ELPLL08. For other options, please contact Artome representatives. | ||
| Brightness | up to 10 000 lumens | ||
| Sound | Embedded 2.1. -sound system | ||
| Connections | HDMI in, 2pcs Mic in, Stereo audio out (balanced), HDBaseT | ||
| Controls | Power, Source, Vol +/-, Pause, Freeze |
